SignBold

Signbold ACM is an aluminum composite panel developed especially for visual communication and interior applications, prioritizing light weight, practicality and production efficiency.

With a standard thickness of 3 mm, Signbold features a lightweight, easy-to-process structure, allowing fast cutting, bending and machining, even in smaller-scale operations. Its mechanical performance is suitable for applications where there is no high structural requirement.

The material offers good dimensional stability in interior environments, in addition to a smooth surface that favors visual finishing, printing, adhesive application and cleaning. It is a functional, economical solution aligned with the needs of the graphic and promotional market.

• The sheets must be stored in a covered, dry place on flat surfaces, protected from direct sun exposure.
• Avoid excessive stacking that could cause deformation or damage to the surface.
• During transport, ensure full support of the sheets to avoid warping and impacts.
• During installation, use compatible fastening systems, respecting clearances for thermal expansion, especially in larger applications.
• For permanent outdoor use, it is recommended to evaluate products with paint suitable for high weather exposure.

• ACM thickness 3 mm
• Aluminum thickness of the colored face 0.18 mm
• Aluminum thickness of the back face 0.18 mm
• Aluminum thickness variation ±0.02 mm
• Weight 4.2 kg/m2
• Length variation tolerance -3 / +3 mm
• Width variation tolerance – 2 / +2 mm
• Thickness variation tolerance ± 0.20 mm
• Longitudinal roughness ≤3
• Coating flexibility 2T
• Impact resistance 50 Kg/m² – No peeling and no cracking
• Grinding resistance 10.3 L/um
• Resistance to pollutants 3.18%
• Abrasion resistance No changes up to 1000 cleanings
  involving scrubbing
• Acid resistance 1.48 ΔE
• Alkali resistance 0.19 ΔE
• Flexural strength 151 Mpa
• Elastic modulus for bending 7×10^4 Mpa
• Penetration resistance 8.65 KN
• Shear strength 28 Mpa
• Peeling strength 164 Mpa
• Thermal expansion coefficient 1.28×10^-5 °C^-1
• Core composed of recycled Polyethylene 1.4 g/cm³
• Paint Polyester
• Paint thickness From 15 to 18 μm
• Allowed color variation △ ≤2.0
• Cleaning processes before painting Degreasing and Chromating
• Gloss ±10%
• Temperature resistance From -50 to 95°C
• Heat distortion temperature 102°C
